IP69K Marine Grade Stainless Steel Scale

IP69K Marine Grade Stainless Steel Scale

The XK combines the proven robust X320 indicator with a rugged X Series base equipped with an IP69K load cell to handle the toughest weighing application.  An ideal general purpose or check weighing scale for marine and food processing applications and for:

  • Tough environments where there is possibility of knocks
  • Where heavy wash down of the indicator and base is needed (IP69K).
  • Where the whole scale including the indicator needs to be submerged for hygienic purposes for example (IP68).
  • Check weighing and general purpose weighing
Tough enclosure
Impact resistant composite alloy indicator housing designed to withstand knocks
Capacitive keys
No moving parts, no membrane to leak or damage
Clear highly visible display
20mm LCD display with LED backlight
Built-in check weigh function
3 coloured high intensity status LEDs
Three outputs – Over, Under, Pass
 High side drivers up to 400mA, to drive a traffic light pole for example
IP69K Rated
IP69K environmental rated means:
  • high pressure water jets (1450psi)
  • high temperature (up to 80oC)
  • from multiple angles.

Standard X Scale Series features:

Built-in RS232 Connection to printer, PC or display
Configurable printing Link to a printer for customised reports, printouts and dockets.
Built in clock calendar For date and time stamping
Three power options AC, DC and rechargeable NiMH battery options
Dedicated function keys Zero, Tare, Gross/Net

Pan Size -A Dual Range Capacity
Capacity (kg) 310 x 310mm Range 1 Range 2
15 ● 6 x 0.002 kg 15 x 0.005 kg
30 ● 15 x 0.005 kg 30 x 0.01 kg
60 ● 30 x 0.01 kg 60 x 0.02 kg
SKU: 1045 Category:

Description

Key Highlights & Features

  • Check weighing
  • Heavy washdown applications
  • Marine environment
  • Marine grade (316) stainless steel throughout
  • Trade approved NMI 6/4C/256
  • X320 IP68 and IP69K indicator

Product Description

The XK combines the proven robust X320 indicator with a rugged X Series base equipped with an IP69K load cell to handle the toughest weighing application.  An ideal general purpose or check weighing scale for marine and food processing applications and for:

  • Tough environments where there is possibility of knocks
  • Where heavy wash down of the indicator and base is needed (IP69K).
  • Where the whole scale including the indicator needs to be submerged for hygienic purposes for example (IP68).
  • Check weighing and general purpose weighing
Tough enclosure
Impact resistant composite alloy indicator housing designed to withstand knocks
Capacitive keys
No moving parts, no membrane to leak or damage
Clear highly visible display
20mm LCD display with LED backlight
Built-in check weigh function
3 coloured high intensity status LEDs
Three outputs - Over, Under, Pass
 High side drivers up to 400mA, to drive a traffic light pole for example
IP69K Rated
IP69K environmental rated means:
  • high pressure water jets (1450psi)
  • high temperature (up to 80oC)
  • from multiple angles.

Standard X Scale Series features:

Built-in RS232 Connection to printer, PC or display
Configurable printing Link to a printer for customised reports, printouts and dockets.
Built in clock calendar For date and time stamping
Three power options AC, DC and rechargeable NiMH battery options
Dedicated function keys Zero, Tare, Gross/Net

Pan Size -A Dual Range Capacity
Capacity (kg) 310 x 310mm Range 1 Range 2
15 ● 6 x 0.002 kg 15 x 0.005 kg
30 ● 15 x 0.005 kg 30 x 0.01 kg
60 ● 30 x 0.01 kg 60 x 0.02 kg

Smart Weighing

built to last

  • 316 marine grade stainless construction throughout
  • 6mm robust frame
  • Over load protection stops
  • 1.2mm thick pan
  • Overload recording increments every time the scale is overloaded

easy maintenance & operation

  • Clear open frame  Easy to keep clean.
  • Removable low sided pan  Deflect splatter
  • Sturdy pan construction  No warping
  • Ergonomic shaped pan  To assist operators
  • 2 Axis rotating head  For best operator viewing angle

..now that's smart weighing.

Product Downloads

The following files are available for download for the IP69K Marine Grade Stainless Steel Scale. Ensure you select the correct documentation for your unit's software version. Check back regularly for software and other updates.

To download files, please click on a filename below. A save dialogue box should appear allowing you to specify your save location.

If a save dialogue box does not appear, right click on the link and select save target as.
